Overview
Introducing the Nano ESP32, a robust addition to the Arduino framework that brings the appreciated ESP32-S3 to the realm of Arduino and MicroPython programming. For novices beginning to explore the Internet of Things or MicroPython, or experts seeking to integrate it into their next product, the Nano ESP32 is the ideal option. It knits together all of the essential aspects for launching your IoT or MicroPython endeavor with comfort.
Let's explore the key features of the Nano ESP32:
- Tiny footprint: Designed with the well-known Nano form factor in mind, this board's compact size makes it perfect for embedding in standalone projects.
- Wi-Fi® and Bluetooth®: Harness the power of the ESP32-S3 microcontroller, well-known in the IoT realm, with full Arduino support for wireless and Bluetooth® connectivity.
- Arduino and MicroPython support: Seamlessly switch between Arduino and MicroPython programming with a few simple steps. We even offer an introductory course for those new to the MicroPython world, find more information in the .
- Arduino IoT Cloud compatible: Quickly and easily create IoT projects with just a few lines of code. Our setup takes care of security, allowing you to monitor and control your project from anywhere using the . (Available starting August 2023)
- HID support: Emulate human interface devices, such as keyboards or mice, over USB, opening up new possibilities for interacting with your computer.
There are no more excuses to delay your exploration of IoT and MicroPython. The Nano ESP32 provides everything you need to start creating and discovering the endless possibilities.
Arduino IoT Cloud Compatible*
Use your board on Arduino's IoT Cloud, a simple and fast way to ensure secure communication for all of your connected Things.
Tech specs
Board | Name | Arduino® Nano ESP32 with headers |
SKU | ABX00083 | |
Microcontroller | u-blox® NORA-W106 (ESP32-S3) | |
USB connector | USB-C® | |
Pins | Built-in LED Pin | 13 |
Built-in RGB LED pins | 14-16 | |
Digital I/O Pins | 14 | |
Analog input pins | 8 | |
PWM pins | 5 | |
External interrupts | All digital pins | |
Connectivity | Wi-Fi® | u-blox® NORA-W106 (ESP32-S3) |
Bluetooth® | u-blox® NORA-W106 (ESP32-S3) | |
Communication | UART | 2x |
I2C | 1x, A4 (SDA), A5 (SCL) | |
SPI | D11 (COPI), D12 (CIPO), D13 (SCK). Use any GPIO for Chip Select (CS) | |
Power | I/O Voltage | 3.3 V |
Input voltage (nominal) | 6-21 V | |
Source Current per I/O Pin | 40 mA | |
Sink Current per I/O Pin | 28 mA | |
Clock speed | Processor | up to 240 MHz |
Memory | ROM | 384 kB |
SRAM | 512 kB | |
External Flash | 128 Mbit (16 MB) | |
Dimensions | Width | 18 mm |
Length | 45 mm |
